Syntactic Natural Gas (SNG)

• Integrated unit comprised of an XP electric vaporizer and matching venturi mixer.
• This unit is similar to the XPV system but does not include an integrated surge tank, thus permitting connection to a locally supplied surge tank.
• The vaporizing section transforms incoming liquid LPG to the vapor phase, while the venturi assembly mixes the vapor LPG with atmospheric air to produce a natural gas compatible air/gas mixture
• Systems available for use with commercial grade propane and propane/butane mixtures (LPG)
• FM Approved
• Capacities: 2.5 – 14 MMBTU/hr

DFV propane-air mixing systems from Algas-SDI are self contained units providing a mixture of LP-gas vapor and air which can replace natural gas. These compact systems are available in a variety of sizes ranging from 2.5 – 42 million BTU/Hr at delivery pressures from 5 to 12 psig atmospherically. DFV systems use the Algas-SDI Direct Fired vaporizers and the Algas-SDI atmospheric venturi system packaged together with an ASME constructed accumulator tank. The gas is mixed with air in the venturi and stored in the accumulator tank to provide uninterrupted flow of mixed gas from full flow to zero flow, automatically.

A liquid pump such as the Algas-SDI STABILAIRE pump system may be required to provide sufficient gas pressure for the mixing process.

• 100% turndown means these units are perfect for variable or steady loads
• Economical solution to lower gas bills
• Ensures your plant or facility will never be without gas
• 110V/50-60Hz or 220V/50-60Hz
• Electrical consumption less than 1 amp
• Gas fired vaporizer with electric control system
• Systems up to 12 psig discharge pressure do not require compressed air
• Capacities: 2.5 – 42 MMBTU/hr

The Algas-SDI QM natural gas replacement system is a combination gas fired waterbath LPG vaporizer and atmospheric venturi LPG/air mixer. All QM models feature an Eclipse Combustion ThermAir forced draft burner and Algas-SDI optimized venturi mixers. Operation of these units has been proven in -40 F climates. PLC controls with an easy to use operator interface are provided in a temperature controlled enclosure to ensure long-term reliable operation. A “Smart-Start” cold start feature automatically senses and controls the inlet propane pressure to make sure only vapor is fed to the burner until the bath is warm enough for full vaporization. When the bath has reached operating temperature an output is switched by the PLC that turns on the LPG pump (STABILAIRE). A maintenance program tracks the hours used, venturi cycles, and burner cycles to allow the user to schedule service accordingly. Flow totalization is also provided for convenience.

• Compact system comprised of vertical waterbath vaporizer and atmospheric venturi mixer
• A forced draft burner keeps the waterbath at optimum vaporizing temperature
• Powder coated galvanized steel cabinet
• Easy to use Operator Interface with PLC and smart controls
• Integral heavy ends trap keeps the “gunk” out of the venturi controls
• Heavy duty water pump provides circulation and prevents temperature stratification
• Systems 100 million and larger use a single pilot operated venturi regulator for robust, consistent control and easy adjustment
• Delivery pressures up to 15 PSIG available with commercial propane feedstock, up to 8 PSIG with butane rich LPG, and up to 40 PSIG with compressed air
• FM Approved
• Capacities: 28 – 150 MMBTU/hr
